EP1020R
ViewSonic’s EP1020r wireless display is just right for POS messaging or meeting room schedules. It features a built-in media player with internal storage capable of playing of JPEG images and video content with audio. Vivid retail messaging is easily configured via a play list, using the included Signage Manager Express Software and uploaded into the EP1020r display over a corporate network or manually using a USB thumb drive. Great for advertising in high visibility locations, informational signs for hotel lobbies and public locations, even for advertising boards in banks and on university campuses. The EP1020r is also SMIL compatible making the perfect companion for ViewSonic’s new ScheduleIT software for automated meeting room scheduling.
- • 10.4" wireless display with integrated media player
- • 800x600 display resolution
- • Signage Manager Express: Content scheduling and management software – MS Windows compatible
- • Supports photos: Video music and Text – JPEG, MPEG 1, MPEG-4ASP, DivX, BMP
- • Easy loading of content through USB or Network (RJ45) Ethernet
- • Built in 3W x2 audio
- • Compatible with ViewSonic Schedule IT automated meeting room scheduling software
DISPLAY
- • Resolution: 800x600 dots
- • Display size: Diagonal: 10.4" (4:3) TFT LCD
- • Brightness: 250 cd/m2 (typ)
- • Contrast Ratio: 400:1 (typ)
- • Color Depth: Over 16.7M color (depending on video card used)
- • Response Time: 8ms (typ gray-to-gray)
- • Viewing Angles: Up and down 178º, left and right 178º (typ) @ CR>10
- • Storage 2GB Compact Flash
COMPATIBILITY
- • Photo Formats: JPEG baseline 5120x3840, progressive 2048x1536
- • Audio Formats: LPCM, sampling rate: 32–48KHZ/16–24 bit, MPEG1 Layer 3, sampling rate: 32–48KHZ, bit rate: 32–320Kbps
AUDIO
CONNECTOR
- • USB: 1.1 (x1)
- • Ethernet: RJ45 (10/100M)
POWER
- • Consumption: Max 24W
- • Save Mode (W): Off < 1W
- • Supply: 3.2–1.38 A @ 100–240VAC, 50/60Hz
OPERATING CONDITIONS
- • Temperature: 32–122º F (0–40º C)
- • Humidity: 5–85% (non-condensing)
REGULATIONS
PACKAGE CONTENTS
- • ePoster, AC adapter, stand, antenna, Quick Start Guide and Software on CD
DIMENSIONS (W x H x D)
- • Physical: 9.9" x 7.8" x 1.7" (251mm x 198mm x 43mm)
WEIGHT
- • Net: 4.0 lbs. (1.8 kg)
- • Gross: 5.3 lbs. (2.4 kg)
STORAGE ENVIRONMENT
- • Temperature: 0–40º F (32º–122º C)
- • Humidity: 10–90% (non-condensing)
