CD4233
ViewSonic’s 42" CD4233 Commercial Display is designed for use in educational, retail, public and commercial signage applications. Full 1080p resolution provides a clear view in any installation. Generous screen size and super slim bezel make messages stand out in a big way. Multiple connectivity and resolutions provide you with lots of options for showing a diverse set of digital signage content; from video, to internet pages, PowerPoint, Flash, and much more with ultimate HD clarity. Display your vivid graphics and stunning video beautifully with this large, bright and high contrast screen.
- • 1080p 9ms panel for vibrant video and crisp images
- • 16.3mm slim bezel
- • 7 day on/off scheduling
- • Display wall capability up to 5x5
- • Installation options include stand or VESA® wall mount
- • Remote and panel control lockout
- • RS-232 daisy-chain capable
- • Screen saver/image sticking protection
- • VGA and DVI inputs/outputs for flexible connectivity and control
LCD
- • Type: 42" color TFT active matrix, wide LCD
- • Display Area: 36.6" horizontal x 20.6" vertical; 42" diagonal
- • Optimum Resolution: 1920x1080, 600mm dot pitch
- • Contrast Ratio: 1100:1 (typ)
- • Viewing Angles: 178º horizontal, 178º vertical
- • Response Time: 9ms
- • Light Source: Long life, 50,000 hrs. (typ)
- • Brightness 700 cd/m2 (typ)
- • Aspect Ratio: 16:9
- • Panel Surface: Anti-glare, hard coating (3H)
INPUT
- • Video Input: HDMI, DVI, component, VGA, S-Video, composite
- • Video Output: VGA, component, DVI
- • Control Input/Output: RS-232
AUDIO
- • Amplifier: 7-watt / 8 ohm
CONNECTOR
- • Analog: 15-pin mini D-sub (VGA)
- • Digital: HDMI, DVI
- • Power 3-pin plug
POWER
- • Voltage: AC 100–240V (universal), 50–60Hz
280W (twp)
CONTROLS
- • Picture: Picture mode, contrast, brightness, color temperature, temperature adjust, sharpness
- • Audio: Volume, mute, audio source
- • Panel: Power, Exit, +, –, Menu/Enter
- • VGA Setting: Auto adjustment, clock, phase, sharpness, H. position, V. position
- • OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
- • Special Aspect ratio, over scan, power save, image retention, auto adjustment, monitor ID, reset
- • Diagnostic: Thermal, back light, ambient, 5V detect, 12 detect
- • Input: VGA, DVI, HDMI, YPbPr
OPERATING CONDITIONS
- • Humidity 20–80% (non-condensing)
- • Temperature (landscape): 41–104ºF (5–40ºC)
- • Temperature (portrait): 41–95ºF (5–35ºC)
DIMENSIONS (WxHxD)
- • Physical Without Stand: 38.1" x 22.0" x 4.9" (967.6mm x559.6mm x 123.1mm)
- • Physical with stand (optional): 38.1" x 25.5" x 15.9" (967.6mm x 647.7mm x 403.9mm)
WEIGHT
- • Net With Stand 69.8 lb. (31.7 kg)
- • Net Without Stand 65.0 lb. (29.5 kg)
- • Gross without stand 76.5 lb. (34.7 kg)
REGULATIONS
- • FCC, ICES003, UL, cUL, CE, CB, ENERGY STAR®
WALL MOUNT
- • VESA 100mm x 100mm, 12 holes
RECYCLE/DISPOSAL
- • The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS
- • LCD display, power cable, remote control with batteries, User Guide CD.
WARRANTY
- • Three-year limited warranty on parts, labor and backlight.
