CDP6530
ViewSonic’s new CDP6530 full HD commercial display with 1920x1080p, 500 nits panel with 20,000:1 dynamic contrast ratio. Additional features include versatile inputs – HDMI, DVI, VGA, S-video and composite, YPbPr (BNC) with built-in 12Wx2 speakers and 12Wx2 speaker output connections. The CDP6530 can be used to make up to a 5x5 display video wall applications and automatic scheduler. RS232 daisy chain and DDC/CI is also provided for remote control. VGA and composite video output is also provided for video loop through applications.
- • 1080p 8ms LED panel for vibrant images using up to 35% less power* than standard CCFL displays
- • 42.3mm bezel with 5x5 display video wall capability
- • Versatile inputs include – HDMI, DVI, VGA, YPbPr, CVBS (BNC) S-video and composite video
- • Designed for 24/7 operation with 3-year limited warranty 500 nits brightness with 20,000:1 dynamic contrast ratio
- • RS232 daisy-chain capable
- • Remote and panel control lock out
- • Built-in 12Wx2 speakers
- • Installation options include stand or VESA® wall mount
- • PIP (Picture-in-Picture) >>Internal Scheduler
LCD
- • Type: 65" (64.6" viewable) color TFT active matrix, wide LCD
- • Display Area: 56.2" horizontal x 31.6" vertical; 64.6" diagonal
- • Optimum Resolution: 1920x1080, 600mm dot pitch
- • Contrast Ratio: 5000:1 (typ)
- • Viewing Angles: 178º horizontal, 178º vertical
- • Response Time: 8ms
- • Light Source: Long life, 50,000 hrs. (typ)
- • Brightness 500 cd/m2 (typ)
- • Aspect Ratio: 16:9
- • Panel Surface: Anti-glare, hard coating (3H)
INPUT
- • Video Input: HDMI, DVI, component, VGA, S-video, CVBS (BNC)
- • Video Output: VGA, component, DVI (Loop through)
- • Control Input/Output: RS-232
AUDIO OUT
- • Speakers: Internal 12-watt (x2)
AUDIO
- • Amplifier: 12-watt / 8 ohm
INPUT SIGNAL
- • TV/Video comp.: 480i, 480p, 720p, 1080i, 1080p
CONNECTOR
- • Analog: 15-pin mini D-sub (VGA)
- • Digital: HDMI, DVI, S-video YPbPr, CVBS
- • Power 3-pin plug
POWER
- • Voltage: AC 100–240V (universal), 50–60Hz
- •Consumption: 520W (typ)
CONTROLS
- • Picture: Picture mode, contrast, brightness, color temperature, temperature adjust, sharpness
- • Audio: Volume, mute, audio source
- • Panel: Power, Exit, +, –, Menu/Enter
- • VGA Setting: Auto adjustment, clock, phase, sharpness, H. position, V. position
- • OSD Setting Languages, OSD H. position, OSD V. position, OSD timer
- • Special: Aspect ratio, over scan, power save, image retention, auto adjustment, monitor ID, reset
- • Diagnostic: Thermal, back light, ambient, 5V detect, 12 detect
OPERATING CONDITIONS
- • Humidity: 20–90% (non-condensing)
- • Temperature (landscape): 32–104ºF (0–40ºC)
- • Temperature (portrait) 41–95ºF (5–35ºC)
RESOLUTIONS
- • 640 x 480 at 60 Hz to 75 Hz 800 x 600 at 60 Hz, 60Hz to 75 Hz 1024 x 768 at 60 Hz, 60Hz to 75 Hz 1280 x 768 at 60 Hz, 60Hz to 75 Hz 1360 x 768 at 60 Hz, 60Hz to 75 Hz 1280 x 1024 at 60Hz 1600 x 1200 at 60 Hz 1920 x 1080 at 60Hz (recommended resolution) NTSC, SECAM, 4.43 NTSC Component: 480i,480p,720p,1080i,1080p
DIMENSIONS (WxHxD)
- • Physical: 59.3" x 35.4" x 5.3" (W x H x D) (1500mm x 900mm x 136mm)
WEIGHT
- • Net: 154.3 lb. (70.0 kg)
- • Gross 176.4 lb. (80.0 kg)
REGULATIONS
- • FCC, ICES003, UL, cUL, CE, CB, ENERGY STAR®, RoHS
RECYCLE/DISPOSAL
- • The lamp in this product contains mercury. Please dispose of in accordance with local, state or federal laws.
PACKAGE CONTENTS
- • LCD display, power cable, remote control with batteries, User Guide CD.
WALL MOUNT
- • VESA 200mm x 400mm, 400mm x 400mm
OPTIONAL ACCESSORIES AVAILABLE
- • Stand (optional), Wall Mount (WMK-013), Wall Mount with Locking Media Player Cradle (WMK-028)
WARRANTY
- • Three-year limited warranty on parts, labor and backlight.
