Description |
2U DP , 6 x Hotswap HDDs , SAS/SATA 6G B/P , Ideal For General Purpose Server |
M/B Form Factor |
EEB (12"X13") |
Security |
Intrusion Switch |
Chassis Dimension |
D x W x H (mm): 660 x 430 x 88 (mm) D x W x H (inch): 26" x 16.9" x 3.5" |
Drive Bay |
Hot-Swap 3.5" : 6 (SAS/SATA 6G B/P) External 5.25" : 1 External 3.5" : 1 |
Expansion Slots |
FF: 3 |
Front Panel |
Front Control: Power On/Off, System Reset, Alarm mute Indicator: Power Status, HDD Activity (x1), LAN Activity (x1), Fan/Overheat Failure Ports: USB 2.0 x 2 |
Mother board |
Intel Server Board S5520 HCR |
Processor |
Intel Xeon Six Core |
Hard Drive |
500 GB SATA |
Network |
On Board dual 10/100/1000 Mbps |
Operating System |
Server 2008 R2 *Linux OS is available (Support will be available thru software developer only) |
Controller |
Raid Controller (0/1/5/6)with transfer rate of 6GB/s and up |
Power Supply |
Form Factor: Redundant Watt: Option Redundancy : 1+1 |
System Cooling |
Middle: 4 x 80mm (T=32mm) non hot-swap fans Rear : 2 x 40mm (T=28mm) fans (Optional) |
