Description |
1U 2x 3.5" Hot-swap Bay Storage Chassis |
M/B Form Factor |
EEB (12"X13") |
Support Backplane |
6Gb/s SATA |
Security |
Intrusion Switch |
Chassis Dimension |
D x W x H (mm): 660 x 430 x 43.5 D x W x H (inch): 26" x 16.9" x 1.7" |
Drive Bay |
Hot-Swap 3.5": 2 Slim ODD : 1 Slim FDD : 1 |
Expansion Slots |
FF: 1 |
Slide Rail |
Optional |
Front Panel |
Front Control: Power On/Off, System Reset Indicator: Power LED, HDD Activity LED, LAN Activity LED x 2 Ports: USB 2.0 x 2 |
Mother board |
Intel Server Board S5520 HCR |
Processor |
Intel Xeon Six Core |
Hard Drive |
500 GB SATA |
Network |
On Board dual 10/100/1000 Mbps |
Operating System |
Server 2008 R2 *Linux OS is available (Support will be available thru software developer only) |
Controller |
Raid Controller (0/1/5/6)with transfer rate of 6GB/s and up |
Power Supply |
Form Factor: 1U Single or Redundant Watt: Option Redundancy : Option |
System Cooling |
Front: 4x 40mm (T48), PWM |
